MULTISWITCHES STAND ALONE 17 INPUTS

Standalone multiswitches for distribution of 16 SAT IF polarisations and terrestrial signals.

Green Line 17 IN stand alone16 SAT and 1 terrestrial TV input
energy efficient
built-in amplifier to compensate cable loss
switching commands 14/18 V, 0/22 kHz and
DISEqC 2.0
high return loss
high isolation between the polarisations

Typ / Type

PSG 1708 P

PSG 1712 P

PSG 1716 P

Artikel-Nr. / Article no.

9268190

9268200

9268210

Eingänge / Inputs

16 SAT, 1 TERR

Ausgänge / Outputs

Eingangsdämpfung / Insertion loss SAT
950-2150 MHz

2 dB

Eingangsdämpfung / Insertion loss Terr.
40-862 MHz

21 dB

24 dB

Schaltkriterien / Switching commands

14 V / 18 V / 0/22 kHz / DiSEqC 2.0

Entkopplung / Isolation Horz. / Vert.

> 28 dB

Entkopplung / Isolation SAT / Ter.

> 30 dB

Eingangspegel max. / Input level max.

SAT: 95 dBµV ; TERR: 95 dBµV

Stromaufnahme je Receiver / Power consumption per receiver

50 mA

LNB-Stromversorgung / LNB supply

max. 2400 mA

Betriebstemperatur / Operation temperature

-20…+50 °C

Betriebsspannung / Operating voltage

180-264 VAC, 47-63 Hz

Maße (B x H x T) / Dimensions (W x H x D) [mm]

370 x 128 x 54

370 x 209 x 54
